Key facts
- Manuals
- 17
- Models
- 5
- Categories
- 1
- Languages
- JA · EN · ZH
- Last added
- 2026-10-01
SATO models by category
Featured SATO manuals
Sato ML-400-NH Terminal Datasheet
The ML-400-NH is a 7.62 mm pitch terminal made of P.P.E. (UL94V‑1) with a gray body and button made of P.P.E. (UL94V‑0). It is rated for 250 V‑7 A, offers insulation resistance of at least 1000 MΩ at 500 V DC, and can withstand 2000 V AC for one minute. The terminal supports 1 to 15 poles and accommodates single‑wire (Ø1.0 mm, AWG18) and stranded wire (0.75 mm²) sizes.
Ordering is done by specifying the pole count (e.g., ML-400-NH‑2P). Recommended installation tools include a minus screwdriver with a 3 mm shaft and 2.6 mm tip width. Users should avoid washing the button and note that terminals with more than 15 poles may show slight machining marks. This manual is written in Japanese.
Covers: Specifications · Electrical Ratings · Dimensions · Materials · Recommended Tools · Ordering Information
SATO S84-ex/S86-ex Programming Reference
This document provides a complete list of printer commands, font definitions, barcode and 2D code specifications, as well as graphics and system commands for SATO S84‑ex and S86‑ex models. It also details the communication interfaces, their electrical characteristics and configuration procedures.
The reference includes interface specifications for RS‑232C, IEEE1284 parallel, USB, LAN, wireless LAN and Bluetooth, along with example command sequences and memory‑card handling instructions.
Covers: Programming Reference · Interface Specification · RS‑232C · USB · LAN / Wireless LAN · Bluetooth
SATO 408E/412E Barcode Printer User Manual
This manual explains how to perform electrical checks, sensor calibrations, ribbon tension adjustments, and print‑head alignment for SATO barcode printers. It includes voltage test points, potentiometer settings, and detailed procedures for major and minor adjustments.
The document provides safety notes, required tools, and illustrated steps to ensure consistent print quality and reliable operation of the 408E/412E models.
Covers: Electric Checks and Adjustments · TP Test Point Chart · Potentiometer Adjustments · Ribbon Clutch Adjustment · Print Head Position Alignment · Minor Adjustment
Sato FG-5000 Series Force Gauge User Manual
This manual describes the Sato FG-5000 series force gauges, which measure tensile and compressive forces with high accuracy. It covers features such as large displays, zero‑adjustment, overload protection, and RS232C PC interface.
The document lists detailed specifications for each model, operating environment limits, measurement modes (FAST/SLOW), power options, and optional accessories like a USB‑O1 PC connection set. This manual is written in Japanese.
Covers: Specifications · Operating Environment · Main Applications · Measurement Modes · PC Connection · Optional Accessories
Latest SATO manuals
Sato ML-400-NH Terminal Datasheet
Datasheet 2 pages · 171 KB · JAThe Sato ML-400-NH terminal datasheet provides electrical ratings, dimensions, material specifications, and ordering information.
SATO S84-ex/S86-ex Programming Reference
Programming Manual 489 pages · 9.7 MB · ENProgramming reference for SATO S84‑ex and S86‑ex label printers covering commands, interfaces and system settings.
SATO CX400 Desktop Printer user manual
This document is the user guide for the CX400 desktop printer, which provides specifications, operation instructions, and contact information.
SATO 408E/412E Barcode Printer User Manual
User Manual 10 pages · 1.1 MB · ENStep‑by‑step guide for checking power, sensor, ribbon tension and print‑head adjustments on SATO 408E/412E barcode printers.
Sato FG-5000 Series Force Gauge User Manual
User Manual 1 pages · 425 KB · JAThe Sato FG-5000 series force gauge user manual provides specifications, operation instructions, and connection details for models FG-5005, FG-5020, and…
SATO DR300 Barcode Label Printer Product Leaflet
Product Leaflet 2 pages · 110 KB · ZHThe SATO DR300 barcode label printer product leaflet provides specifications, features, and interface details for the printer.
SATO Label Gallery Easy SI-040603-02 Manual
User Manual 101 pages · 690 KB · ZHThe SATO Label Gallery Easy user manual provides installation steps, quick‑start instructions, and usage guidance for the label design and printing software.
SATO GT408e/GT412e/GT424e Label Barcode Printer Manual
User Manual 1 pages · 99 KB · ZHThe SATO GT408e/GT412e/GT424e industrial label barcode printer manual provides specifications, features, and operating details.
SATO CT400/410 Industrial Barcode Label Machine User Manual
User Manual 2 pages · 117 KB · ZHThe SATO CT400/410 manual details specifications, printing methods, interfaces and operating conditions for the industrial barcode label printer.
SATO M10e Barcode Label Machine Product Leaflet
Product Leaflet 2 pages · 111 KB · ZHThe SATO M10e barcode label printer specification sheet lists printing methods, dimensions, performance and interface details.
SATO CL408e/CL412e Barcode Printer Manual
Product Leaflet 2 pages · 117 KB · ZHThe SATO CL408e and CL412e barcode printer manual provides specifications, features, and usage guidelines.
SATO M84Rve Barcode Label Printer Product Leaflet
Product Leaflet 2 pages · 114 KB · ZHThe SATO M84Rve barcode label printer product leaflet provides specifications, features, and interface options.
Sato SK-8940 Infrared Line Temperature Meter User Manual
User Manual 2 pages · 459 KB · JAThe Sato SK-8940 infrared line temperature meter user manual provides operating instructions, specifications, and safety information.
Sato PRO2 Industrial Endoscopic Mirror Manual
User Manual 4 pages · 1.2 MB · JAThe Sato PRO2 industrial video endoscope manual provides operating instructions, specifications, and accessories for the waterproof mirror inspection system.
Sato SK-L210T Temperature Logger User Manual
User Manual 2 pages · 829 KB · JAThe Sato SK-L210T temperature logger manual provides specifications, operation modes, and setup instructions for the two‑channel device.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Programming Manual
Instruction set, parameters and examples for configuring or programming the device.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in SATO manuals
What is the pitch of the ML-400-NH terminal?
The terminal has a 7.62 mm pitch.
What are the recommended tools for installing the terminal?
A minus screwdriver with a 3 mm shaft and a 2.6 mm tip is recommended.
What communication interfaces are supported by the S84‑ex/S86‑ex printers?
The printers support RS‑232C, IEEE1284 parallel, USB, LAN, wireless LAN and Bluetooth interfaces.
How can the baud rate be set for the RS‑232C interface?
Baud rate can be selected from 2400 to 115200 bps in the communication setting mode.
What voltage should be measured at test point 0?
The voltage at test point 0 should be +5.0 VDC, within a range of +4.8 V to +5.2 V.
What is the correct ribbon unwind tension?
The ribbon unwind tension should be between 450 g and 550 g.
