This document is about the product specification of Emerson 3SCH-1000 semi-hermetic piston compressor. The compressor has a nominal input power of 10 HP and features a scroll semi-hermetic design. It has a starting current of 106A and a maximum operating current of 22.8A. The dimensions of the compressor are 655mm×370mm×480mm and it weighs 159kg. The suction port and discharge port sizes are 1 3/8 and 1 1/8 respectively. It is suitable for R22 refrigerant and offers efficient cooling performance.
The guide presents the key technical specifications of the Emerson 3SCH-1000 semi‑hermetic reciprocating compressor, including power rating, cylinder count, bore‑stroke dimensions, displacement, and heating requirements. Detailed performance tables list capacities, input power and operating temperatures for various conditions.
Additional sections provide a wiring diagram, name‑plate example, and recommended compressor configuration with accessories. Dimensional drawings and connection standards are included to aid installation and service planning. This manual is written in Japanese.
| Horsepower (HP) | 10 |
|---|---|
| Number of Cylinders | 3 |
| Bore x Stroke (mm) | 60.4 x 0.8 |
| Displacement (m³) | 38.0 |
| Locked Rotor Amps (LRA) TFD (A) | 106 |
| Maximum Current (MCC) TFD (A) | 22.8 |
| Crankcase Heater Power (W) | 70 |
| Oil Charging Capacity (L) | 3.7 |
| Net Weight (kg) | 159 |
| Gross Weight (kg) | 174 |
The 3SCH-1000 is rated at 10 HP.
It has three cylinders.
The oil charging capacity is 3.7 L.
