This document provides technical specifications for the Emerson brand 4SLW-1500 scroll semi-hermetic piston compressor, including product dimensions, weight, current, and interface sizes.
This guide provides the technical specifications for the Emerson 4SLW-1500 semi‑hermetic reciprocating compressor, including nominal power, cylinder count, bore‑stroke dimensions, displacement, and weight. It also lists the standard mounting size, oil charging volume, and optional configurations such as cooling fans and electronic oil‑pressure controllers.
Additional sections cover performance data across various evaporating and condensing temperatures, the permissible operating envelope, a wiring diagram for electrical connections, and detailed dimension drawings. Contact information for Emerson regional offices in Shanghai, Guangzhou, and Beijing is included at the end of the document. This manual is written in Chinese.
| Model | 4SLW-1500 |
|---|---|
| Nominal Input Power (HP) | 15 |
| Bore x Stroke (mm) | 68.3 x 55.6 |
| Displacement (cc) | 70.8 / 85.0 |
| Discharge Port Size | 1 1/8" |
| Suction Port Size | 1 5/8" |
| Length (mm) | 680 |
| Width (mm) | 485 |
| Height (mm) (no fan) | 495 |
| Mounting Size (mm) | 381 x 305 |
| Oil Charging Volume (L) | 3.4 |
| Net Weight (kg) | 180 |
| Gross Weight (kg) | 207 |
The nominal input power is 15 HP.
The standard mounting size is 381 mm × 305 mm.
The compressor requires 3.4 L of oil.
