This document provides specifications and performance parameters of EMERSON 3SSH-150E semi-hermetic reciprocating compressors. The compressor has a large cooling capacity and input power, making it suitable for refrigeration equipment in low-temperature environments. The document also provides detailed information on the dimensions, weight, and interface dimensions of the compressor.
This manual covers the technical specifications of the Emerson 3SSH-150E semi‑hermetic reciprocating compressor, including power rating, cylinder count, bore‑stroke dimensions, displacement, and heating requirements. It also presents performance tables for various evaporating and condensing temperatures.
Additional sections provide a wiring diagram, detailed dimensions, oil charging information, and application guidelines, along with contact details for Emerson regional offices in China. This manual is written in Japanese.
| Model | 3SSH-150E |
|---|---|
| Nominal Input Power (HP) | 15 |
| Number of Cylinders | 3 |
| Bore x Stroke (mm) | 61.9 x 63.5 |
| Displacement (L) | 49.9 |
| LRA (A) | 125 |
| MCC (A) | 31.1 |
| Discharge Port Size (inch) | 1.38 |
| Suction Port Size (inch) | 1.58 |
| Length (mm) | 680 |
| Width (mm) | 370 |
| Height (mm) | 480 |
| Oil Charging Capacity (L) | 3.7 |
| Net Weight (kg) | 162 |
| Gross Weight (kg) | 177 |
The nominal input power is 15 HP.
It has three cylinders.
It requires 3.7 L of oil for charging.
