This manual provides specifications, installation, operation, and maintenance instructions for the Fisher 3582 series pressure transmitters (3582, 3582i…
The Fisher 3582 series manual describes the pressure transmitter family, its applications, and safety precautions. It includes detailed technical data, wiring diagrams, and calibration procedures for the 3582, 3582i, and 3582NS models.
The document is organized into sections covering specifications, installation steps, operating guidelines, maintenance tasks, and compliance information. Users can reference the flow‑scanner integration notes and part numbers for replacement components. This manual is written in Chinese.
| Pressure range | 0.2–1.0 bar (3–15 psig) |
|---|---|
| Temperature range (3582/3582i) | -50 °C to 71 °C |
| Temperature range (3582NS) | -50 °C to 82 °C |
| Flow capacity at 0.2 bar | 0.38 ± m³/h |
The 3582 series operates from 0.2 to 1.0 bar (3 to 15 psig).
They are rated for –50 °C to 71 °C.
The 3582NS can operate from –50 °C to 82 °C.
