Features and benefits Sizes 2 to 25 circuits Positive latch secures housing to locking crown of mating header or panel mount Anti-entanglement/overstress ribs prevent discrete wires from catching under latch during harness manufacturing and storage Front ribs prevent contact damage when unmating the connector from a header; the housing cannot be twisted off pins
This specification describes the 2.54 mm (.100") pitch SL™ crimp housing 70066, a single‑row connector with a positive latch that secures the housing to mating headers. It lists the available circuit counts (2‑25), anti‑entanglement ribs, front ribs for contact protection, and compatible terminals and crimp pins.
Key technical data include the pitch, pin height, wire size range, material construction, voltage and temperature ratings, and extensive electrical and mechanical performance test results such as contact resistance, insertion force, and environmental durability.
| Pitch (centerline spacing) | .100" (2.54 mm) |
|---|---|
| Maximum mating pin height | .320" (8.13 mm) |
| Minimum mating pin height | .200" (5.08 mm) |
| Wire size range | #22‑#28 AWG stranded, insulation .053" (1.35 mm) max |
| Housing material | Black glass‑filled polyester, UL 94V‑0 |
| Voltage rating | 250 V |
| Operating temperature range | -40 °C to +105 °C |
The connector has a .100 inch (2.54 mm) centerline spacing.
It is rated for operation from –40 °C up to +105 °C.
The connector is rated for a maximum voltage of 250 V.
The housing is made of black glass‑filled polyester and meets UL 94V‑0 flammability standards.
