E2EC series is a high-sensitivity DC 2-wire type that realizes ultra-compact and long-distance detection.
This manual covers the E2EC series proximity switches, describing their electrical characteristics, mechanical dimensions, and environmental requirements. It includes detailed tables of model variants, detection distances, and output types for both DC 2‑wire and DC 3‑wire configurations.
Installation guidance, wiring diagrams, and safety precautions are provided, along with information on metal mounting accessories, IP protection, and recommended operating conditions. The document also lists recommended mounting torque values and accessory part numbers. This manual is written in Chinese.
| Power Supply Voltage | DC5 ~ 24 V |
|---|---|
| Output Type | NPN open‑collector, ≤100 mA |
| Detection Distance (example model E2EC‑CR8D1) | 0.8 mm + 15 % |
| Leakage Current | < 0.8 mA |
| Insulation Resistance | > 50 MΩ |
| Operating Temperature | -25 °C ~ +70 °C |
| Relative Humidity | 35 % ~ 95 % RH |
The device operates on a DC supply from 5 V to 24 V.
