Key facts
- Brand
- Yamaha
- Model
- DSP-A5
- Category
- Player
- Industry
- Appliances
- Documents
- 2
- Languages
- EN · JA
- Last added
- 2012-07-02
Start here
Yamaha DSP-A5 Owner's Manual
The Yamaha DSP-A5 is a 5-channel power amplifier featuring multi-mode digital sound field processing, including Dolby Pro Logic, Dolby Digital, and DTS decoders. It supports 96-kHz/24-bit D/A conversion and includes a Cinema DSP function that combines Yamaha DSP technology with these decoding formats.
The document covers getting started with the unit, including remote control setup and connection guides. It details the controls and functions such as input selection, volume adjustment, tone controls, and speaker configuration. Advanced operation sections explain delay time settings, speaker output levels, and the use of the sleep timer and preset remote control codes.
Yamaha DSP-A5 specifications
| Minimum RMS Output (0.06% THD, 20 Hz - 20 kHz) | Main: 70W+70W (8Ω), Center: 70W (8Ω), Rear: 70W+70W (8Ω) |
|---|---|
| D/A Converter | 96-kHz/24-bit |
| Digital Signal Input Terminals | 3 Optical/2 Coaxial |
Source: Yamaha DSP-A5 Owner's Manual
All Yamaha DSP-A5 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What batteries are required for the remote control?
The remote control requires AAA, R03, or UM-4 type batteries.
How should the unit be installed regarding ventilation?
Allow a space of at least 20 cm behind, 20 cm on both sides, and 30 cm above the top panel.
