This manual provides safety warnings, installation guidelines, and detailed operating instructions for the TCL HID432 and HID522 television models. It covers picture settings, remote‑control functions, input connections, and troubleshooting tips.
The document includes specifications such as screen size, power consumption, dimensions, and supported video formats, helping users configure the TV for optimal performance. This manual is written in Japanese.
| Screen size (HID432) | 109 cm (43 in) diagonal |
|---|---|
| Screen size (HID522) | 132 cm (52 in) diagonal |
| Power consumption | 200 W |
| Input voltage | 175 V‑240 V, 50‑60 Hz |
| Dimensions (HID522) | 1124 mm × 530 mm × 1375 mm |
| Weight (HID522) | 66 kg |
| Supported AV formats | PAL, NTSC 3.58, NTSC 4.43 |
| VGA input resolution | 640 × 480 @ 60 Hz |
The HID432 has a 109 cm (43 in) diagonal screen.
The television consumes 200 W of power.
It supports AV (PAL, NTSC 3.58, NTSC 4.43) and VGA 640 × 480 @ 60 Hz.
