Start here
Phoenix Contact ME MAX 17.5 3-3 KMGY Product Leaflet
The ME MAX 17.5 3-3 KMGY is a DIN‑rail terminal block with 18 positions. The leaflet lists its housing material (PA 6.6), colour (light gray), and key dimensions such as 99 mm length, 114.5 mm constructional height and 17.5 mm width.
Additional pages detail the explosion‑proof and dimensioned drawings, a list of compatible accessories and ordering data (order number 2713612, EAN 4017918917395). The document also includes the manufacturer's address and compliance notes.
Phoenix Contact 5 3-3 KMGY specifications
| Housing material | PA 6.6 |
|---|---|
| Color | light gray |
| Length | 99 mm |
| Constructional height | 114.5 mm |
| Width | 17.5 mm |
| Number of positions | 18 |
| Weight per piece | 0.06025 kg |
| Order number | 2713612 |
| EAN | 4017918917395 |
| Customs tariff | 85369010 |
Source: Phoenix Contact ME MAX 17.5 3-3 KMGY Product Leaflet
All Phoenix Contact 5 3-3 KMGY documents by type
Questions answered in these manuals
What is the order number for the ME MAX 17.5 3-3 KMGY?
The order number is 2713612.
How many positions does the ME MAX 17.5 3-3 KMGY have?
It has 18 positions.
What material is the housing of the ME MAX 22.5 3-3 KMGY made from?
The housing is made from PA 6.6 polymer.
From: Phoenix Contact ME MAX 22.5 3-3 KMGY Connector Data Sheet
How many positions does the connector have?
It provides 24 positions.
From: Phoenix Contact ME MAX 22.5 3-3 KMGY Connector Data Sheet
