Phoenix Contact GMKDS 3/3-7.62 Handbook
Product Leaflet 6 pages · 135 KB · EN
The GMKDS 3/3-7.62 is a 3‑position screw‑type terminal block designed for 24 A nominal current and 500 V nominal voltage. It features a 7.62 mm pitch and can be assembled by soldering or screw connection.
The handbook lists technical data such as rated surge voltages, insulation material, and approved certifications, as well as available accessories like single covers, marker cards, and a screwdriver. Dimension drawings and part numbers are also included for reference.
Phoenix Contact GMKDS 3 specifications
| Nominal current | 24 A |
|---|---|
| Nominal voltage | 500 V |
| Pitch | 7.62 mm |
| Number of positions | 3 |
| Certifications | CCA, CSA, CUL, GL, GOST, SEV, UL |
All Phoenix Contact GMKDS 3 documents by type
Product Leaflet 2
Questions answered in these manuals
What is the nominal current rating of the GMKDS 3/3-7.62 terminal block?
The terminal block is rated for a nominal current of 24 A.
How many positions does the GMKDS 3/3-7.62 have?
It has three positions.
What is the nominal current and voltage of the GMKDS 3/2-7,62 terminal block?
It is rated for a nominal current of 24 A and a nominal voltage of 500 V.
What certifications does the GMKDS 3/2-7,62 have?
It is certified according to CCA, CSA, CUL, GL, GOST, SEV, and UL.
