ME MAX 22,5 3-3 KMGY is a 24-position connector produced by PHOENIX CONTACT
The ME MAX 22.5 3-3 KMGY is a light‑gray DIN rail bus connector with 24 positions, designed for compact mounting on control panels. It features a PA 6.6 housing, UL 94 V0 flame‑retardant rating, and dimensions of 99 mm × 114.5 mm × 22.5 mm.
The document provides ordering information, dimensional drawings, accessory part numbers, and compliance details such as RoHS status and customs tariff classification. It is intended for engineers and distributors selecting the appropriate connector and related accessories.
| Housing material | PA 6.6 |
|---|---|
| Color | light gray |
| Length | 99 mm |
| Constructional height | 114.5 mm |
| Width | 22.5 mm |
| Number of positions | 24 |
| Customs tariff | 85369010 |
| Weight per piece | 0.06466 kg |
| EAN | 4017918936259 |
| Order number | 2713939 |
The housing is made from PA 6.6 polymer.
It provides 24 positions.
The connector measures 99 mm in length, 114.5 mm in constructional height, and 22.5 mm in width.
