Fluke 1550B Manuals

ManualLib has 8 documents for the Fluke 1550B (Other): 1 quick start guide, 1 service manual, 4 user manuals. Every file can be read online or downloaded as a PDF for free.

Quick Start Guide 1Service Manual 1User Manual 4

Key facts

Brand
Fluke
Model
1550B
Category
Other
Industry
Electronics
Documents
8
Languages
EN · ZH
Last added
2023-10-18

Start here

Fluke 1550B MegOhmMeter Quick Reference Guide

Fluke 1550B MegOhmMeter Quick Reference Guide

Quick Start Guide 8 pages · 588 KB · EN

This guide provides a quick reference for operating the Fluke 1550B MegOhmMeter. It includes key controls such as test voltage selection and ramp test functions. Users are advised to read the full user manual before use.

The device features multiple voltage ranges including 50V, 100V, 500V, 2500V, and 10,000V. It also supports time limit and abort functions for test control. The guide is presented in multiple languages for global accessibility.

Read online

Fluke 1550B specifications

Display Size75 mm x 105 mm
Power Source12 V lead-acid rechargeable battery
Charger Input85 V to 250 V ac 50/60 Hz 20 VA
Dimensions170 mm x 242 mm x 330 mm
Weight3.6 kg (7.94 lbs.)
Operating Temperature-20 °C to 50 °C
Storage Temperature-20 °C to 65 °C
Altitude2000 m
Enclosure SealingIP40
Input Overload Protection600 V AC
Safety ComplianceEN 61010, EN 61557 Parts 1 and 2

Source: Fluke 1550B MegOhmMeter Calibration Manual
