The TSC TTP-244 Plus is a compact thermal printer with 203 dpi resolution, multiple barcode support, and flexible paper handling options.
The TTP-244 Plus thermal printer offers a 203 dpi print resolution and speeds up to 4 ips, making it suitable for a wide range of label and receipt applications. It includes a 32‑bit RISC CPU, 4 MB Flash memory and 8 MB SDRAM, and supports built‑in fonts for multiple languages.
The device provides serial, USB 2.0 and parallel interfaces, an external Ethernet module, and a large paper capacity (up to 300 m of media). It complies with FCC Class A, CE Class A, C‑Tick, TUV/Safety and CCC certifications, and operates in temperatures from 5 °C to 40 °C with 25‑85 % humidity.
| Print resolution | 203 dpi |
|---|---|
| Print speed | 1.5‑4 ips |
| Dimensions (W × D × H) | 232 mm × 288 mm × 156 mm |
| Flash memory | 4 MB |
| SDRAM | 8 MB |
| CPU | 32‑bit RISC |
| Supported 2‑D barcodes | PDF‑417, Maxicode, DataMatrix, QR Code |
| Paper width range | 25.4 mm – 114 mm (1.0" – 4.5") |
| Operating temperature | 5 °C – 40 °C |
| Storage temperature | -40 °C – 60 °C |
The printer provides a resolution of 203 dpi.
It operates between 5 °C and 40 °C (41 °F – 104 °F).
