User manual for the Thermo Scientific Multiskan SkyHigh plate reader, covering installation, operation, software use, safety and maintenance.
The Thermo Scientific Multiskan SkyHigh is a microplate photometer for 6‑, 24‑, 96‑ and 384‑well plates, with optional color cup and touch‑screen models. This manual provides detailed instructions for installing the instrument, connecting it to a computer, and using the SkanIt software for data acquisition and analysis.
Safety guidelines, environmental specifications, power requirements, and a comprehensive maintenance checklist are included to ensure reliable, long‑term operation in laboratory settings. This manual is written in Chinese.
| Operating temperature range | +10 °C to +40 °C |
|---|---|
| Maximum relative humidity (≤31 °C) | 80 % RH |
| Relative humidity at 40 °C | 50 % RH |
| Power supply | 100‑240 V AC, 50/60 Hz |
| Maximum power consumption | 110 W |
| Typical operating power consumption | <27 W |
| Energy‑saving power consumption | <10 W |
| Altitude rating | Up to 2000 m |
The instrument operates from +10 °C to +40 °C. Relative humidity may be up to 80 % when the temperature is ≤31 °C and decreases linearly to 50 % at 40 °C.
It accepts a 100‑240 V AC, 50/60 Hz supply. Maximum power draw is 110 W, typical operation uses less than 27 W, and in energy‑saving mode it uses under 10 W.
The Multiskan SkyHigh is rated for use up to 2000 meters above sea level.
