This manual provides installation, operation, calibration, configuration, and maintenance instructions for the Thermo Scientific 8000WJ Series water‑jacket…
The manual begins with safety warnings and a preface that stresses the need for qualified personnel to perform internal calibration and maintenance. It describes the physical components of the water‑jacket CO₂ incubator, including the heating door, gas sampling port, control panel, water‑jacket fill and drain ports, and leveling feet.
Subsequent sections cover step‑by‑step installation, startup procedures, detailed calibration of temperature, CO₂, O₂ and humidity sensors, configuration of alarm limits, routine cleaning, part replacement (fuses, filters, sensors), and a full specification table for electrical and environmental performance. This manual is written in Chinese.
| Temperature control accuracy | ±0.1°C |
|---|---|
| CO₂/O₂ control accuracy | ±0.1% |
| Supply inlet pressure | 1.034 bars (15 PSIG) |
| Humidity tray capacity | 3 L (0.8 gal) standard |
| Fill port connector | 3/8" hose barb |
Place a bubble level on the shelf, adjust the hex nuts on the leveling feet to raise or lower each side until the level indicates the unit is horizontal.
