The manual provides technical specifications, wiring, power requirements and usage instructions for the SUNSTAR CS-RS01 speed sensor.
The CS-RS01 is a high‑response speed sensor designed for precise position detection and various output modes. It operates with a frequency range of 50 ~ 100 kHz and a positioning accuracy of 0.02 mm.
The document details the sensor's electrical connections, required power supplies (+5 V and +12 V DC), output signal types (PNP, NPN, OC), mechanical dimensions (M16 mounting), and includes contact information for SUNSTAR support. This manual is written in Chinese.
| Operating frequency range | 50 ~ 100 kHz |
|---|---|
| Power supply | +5 V DC, +12 V DC |
| Output signal frequency range | 1 Hz ~ 15 kHz |
| Pulse count | 15000 pulses/min (60 Hz) |
| Mounting size | M16 1.0 mm, M16 1.5 mm |
| Output signal types | PNP, NPN, OC |
The sensor operates from 50 kHz to 100 kHz.
It requires +5 V DC and +12 V DC power inputs.
The sensor can output PNP, NPN, or OC (open‑collector) signals.
