The Sunstar NcR6 sensor datasheet provides mounting dimensions, technical parameters, and performance specifications.
This document presents the technical data for the Sunstar NcR6 pressure sensor, including detailed mounting dimensions for various model sizes and a four‑cable connection method. It lists key electrical characteristics such as supply voltage, input and output resistance, and sensitivity.
Performance specifications cover nonlinearity, repeatability, hysteresis, creep, zero‑output, temperature ranges, and overload limits, allowing engineers to assess suitability for their applications. This manual is written in Chinese.
| Nonlinearity | 0.0–0.5 % |
|---|---|
| Repeatability | 0.035–0.05 % |
| Sensitivity | 2.0 mV/V |
| Supply voltage | 10 V ~ 12 V DC |
| Input resistance | 395 Ω |
| Output resistance | 350 Ω |
| Safe temperature range | -20 °C ~ +70 °C |
The sensor can operate safely from –20 °C to +70 °C.
It requires a DC supply voltage between 10 V and 12 V.
The sensitivity is 2.0 mV per volt of excitation.
