User manual for the PowerFlex 755 inverter's embedded EtherNet/IP adapter, covering installation, configuration, operation, and troubleshooting.
This manual provides detailed instructions for installing and wiring the embedded EtherNet/IP adapter on a PowerFlex 755 inverter. It includes safety guidelines, required tools, and step‑by‑step procedures for connecting the adapter to a network and powering the device.
The guide also describes how to configure IP settings, use the integrated programming software, set data rates, and manage I/O mapping. Additional chapters cover explicit messaging, web‑based diagnostics, firmware updates, and comprehensive troubleshooting with LED status explanations. This manual is written in Chinese.
| EtherNet/IP data rate | 10 Mbps full‑duplex, 10 Mbps half‑duplex, 100 Mbps full‑duplex, 100 Mbps half‑duplex |
|---|---|
| Connection limits | 30 TCP connections, 16 synchronous CIP connections |
| Maximum I/O packets per second | 400 packets (200 input, 200 output) |
| Minimum RPI (Requested Packet Interval) | 2 ms |
| DPI data rate | 500 kbps |
The IP address can be set using the configuration tool or by adjusting the adapter parameters as described in the "Setting adapter IP address" section.
Firmware updates are performed through the "Update adapter firmware" procedure in Chapter 3.
Select the option to restore adapter parameters to factory defaults as outlined in the "Reset adapter" section.
