This manual describes the PowerFlex 700 variable frequency drive, its LCD HIM operation panel, SMART View functions, and the basic concepts of parameter configuration. It explains how to start the drive, adjust speed limits, acceleration/deceleration rates, and monitor fault conditions.
The document also lists technical specifications such as power rating and voltage options, provides fault diagnostics like the "Motor Stalled" alarm, and includes contact information for Rockwell Automation support centers worldwide. This manual is written in Chinese.
| Voltage options | 200 V, 400 V, 480 V |
|---|
It signals that the motor has stalled and shows the time elapsed since the fault occurred.
It supports 200 V, 400 V, and 480 V input configurations.
