The Peavey Impulse 1015 specifications detail its frequency response, power handling, dimensions, mounting options, and IP44 weather resistance.
The Impulse 1015 is a weather‑resistant two‑way loudspeaker featuring a 15" Black Widow woofer and an RX™22N Neodymium compression driver. It delivers a smooth frequency response from 68 Hz to 18 kHz, 97 dB sensitivity, and up to 2 kW peak power handling, while maintaining an IP44 rating for outdoor use.
The cabinet includes two NL‑4 twist‑lock input jacks, a 4‑position screw terminal barrier strip, and multiple mounting points (four M6 inserts on the top and four on the side) for the Peavey VM‑70 bracket, pole mounts, or rigging eyebolts. Safety guidelines recommend a torque of 3.5–4.0 ft‑lb for mounting bolts and specify minimum eyebolts strength.
| Frequency Response | 68 Hz to 18 kHz |
|---|---|
| Impedance | 8 Ω nominal |
| Peak Power Handling | 2 kW peak |
| Dimensions (H × W × D) | 28.3" H × 16.75" W × 15.00" D |
| Weight | 48 lb (21.8 kg) |
The speaker system has an IP44 rating when properly installed.
It has two NL‑4 four‑pin twist‑lock jacks in parallel with a four‑position screw terminal barrier strip.
The recommended torque for the mounting bolts is 3.5 to 4.0 foot‑lbs.
The maximum continuous power handling is 500 W.
