The Peavey Tube Fex user manual provides setup, operation, MIDI, and RAM cartridge instructions for the dual‑tube guitar preamp.
This manual walks you through installing the Tube Fex, connecting it to your guitar and amplifier, and configuring basic settings such as input level, output level, and global EQ. It includes a Quick Start guide, detailed front‑panel descriptions, and wiring diagrams for common configurations.
Later chapters cover program editing, MIDI implementation, RAM cartridge usage, and extensive appendices that list each effect, MIDI SysEx formats, and remote‑editing procedures. Technical specifications and warranty information are provided at the end of the document.
| Frequency Response | 12 Hz to 20 kHz (‑2 dB) |
|---|---|
| Total Harmonic Distortion | < 0.02 % at 1 kHz (1 V RMS) |
| Signal‑to‑Noise Ratio | > 90 dB |
| Input/Output Jacks | Differential or single‑ended XLR balanced outs (‑10 dBV) |
| A/D Conversion | 44.1 kHz, 16‑bit |
| D/A Conversion | 44.1 kHz, 18‑bit |
| Presets / Programs | 256 presets (128 user, 128 factory) |
| Simultaneous Effects | Up to 7 maximum |
| Power Supply | 120 VAC, 60 Hz, 25 W |
The Tube Fex can store 256 presets, with 128 user‑created and 128 factory presets.
Up to seven effects can be active at the same time.
It requires 120 VAC at 60 Hz and consumes about 25 watts.
The frequency response spans from 12 Hz to 20 kHz with a –2 dB tolerance.
