The ALPHA ALPHA6000E and ALPHA6000M series variable frequency drives user manual provides installation, wiring, operation, parameter settings, fault…
This manual covers the complete lifecycle of the ALPHA6000E/ALPHA6000M VFD series. It begins with purchase inspection, then details installation requirements, wiring diagrams for main and control circuits, and safety precautions before power‑up. Subsequent chapters describe keyboard operation, operating modes, parameter programming, and detailed function groups such as vector control, PID, and Modbus communication. The later sections provide fault diagnosis, peripheral device connections, routine maintenance, and warranty information. Appendices include mechanical dimensions, technical specifications, Modbus register tables, and keyboard mounting dimensions. This manual is written in Chinese.
| Operating temperature range | -10 °C to 40 °C |
|---|---|
| Input voltage (3‑phase) | 380 V |
| AI1 analog input voltage range | 0 V‑10 V |
| AI1 analog input current range | 0 mA‑20 mA |
| AO analog output voltage range | 0 V‑10 V |
| Ground resistance requirement | ≤10 Ω |
| Communication interface | RS‑485 |
AI1 accepts either 0‑10 V voltage (30 kΩ impedance) or 0‑20 mA current (250 Ω impedance) as configured by the SW1 switch.
