Chinese user manual for the ADT‑QC400 integrated controller, covering safety, wiring, I/O, communication ports and installation.
This manual provides detailed safety instructions, system overview, and wiring diagrams for the ADT‑QC400 integrated controller used in four‑axis robotic systems. It includes specifications, connector pin‑outs, and recommended installation dimensions.
The document also describes power‑supply requirements, digital I/O configuration, and communication interfaces (COM1, COM2, LAN, USB), along with maintenance and troubleshooting guidelines. This manual is written in Chinese.
| Model | ADT‑QC400 |
|---|---|
| Display | Color LCD, 800 × 600 resolution |
| Control Axes | 4 axes |
| Power Rating | Single‑axis ≤ 1.2 kW, total ≤ 3 kW |
| Communication Interfaces | RS‑232 (2 CH), Ethernet (100 Mbps/10 Mbps), USB 2.0 (2 CH) |
The controller can operate in an ambient temperature range of 0 °C to 60 °C.
It supports four control axes.
The unit requires a single‑phase AC supply of 200 V–230 V at 50 Hz.
