Inovance IS810 Series Multi-Drive Servo Drive User Manual

User manual for the Inovance IS810 series multi‑drive servo drive covering safety, installation, wiring, operation, networking and troubleshooting.

Inovance IS810 Series Multi-Drive Servo Drive User Manual - cover page
Brand
汇川技术
Category
Industrial Robot
Document type
User Manual
Language
Chinese
Pages
116
File format
PDF
File size
6.1 MB
Published
03 October, 2026
Updated
03 October, 2026
MD5 checksum
6477A1D8ECACE75312B3232C00B4184B
PDF
Inovance IS810 Series Multi-Drive Servo Drive User Manual PDF

About this manual

This manual provides comprehensive safety guidelines, mechanical and electrical installation instructions, and wiring diagrams for the IS810 series multi‑drive servo drive. It also details the control circuit connections, basic operation procedures, and EtherCAT network configuration.

The document includes a full parameter list, technical specifications, dimension drawings, optional accessories, and a detailed fault diagnosis section with error codes and corrective actions. This manual is written in Chinese.

What's inside

  • Foreword
  • Safety Precautions
  • Product Information
  • Mechanical Installation
  • Electrical Installation
  • Control Circuit Wiring
  • Basic Operation and Test Run
  • Communication Network Configuration
  • Parameter Tables
  • Fault Diagnosis

Specifications

Input voltage (rectifier unit)380 V‑480 V AC (operating range 323 V‑528 V AC)
Output voltage (inverter unit)350 V‑800 V DC
Carrier frequency4 kHz
Rated power (example model IS810‑20M4T112‑10)45 kW
Download PDF (6.1 MB)
