AutoDome 200 Series Speed Dome Camera System is an affordable, high-speed dome camera featuring a high-performance 18x color camera. It supports multiple standards and optional video and data transmission methods, including Bilinx (over coaxial cable and UTP), fiber optic or even TCP/IP over Ethernet. In addition, remote control, configuration, and firmware updates can be carried out over these cables, giving you full control over your camera.
The Bosch AutoDome 200 series is a modular, high‑speed PTZ camera system that uses an 18× optical zoom color camera and interchangeable CPU, camera, dome, communication and power modules. The modular design lets users upgrade from analog to IP, add night‑vision or tracking functions, and replace individual modules without replacing the whole unit.
The manual covers system features, mounting options, power requirements, video output formats, communication protocols, environmental ratings, and diagnostic tools. It also provides detailed technical specifications for the camera, lens, sensor, power consumption and operating conditions. This manual is written in Chinese.
| Image sensor | 1/4 inch Exview HAD CCD (752 × 582 PAL / 768 × 494 NTSC) |
|---|---|
| Lens | 18× optical zoom (4.1–73.8 mm) |
| Horizontal resolution | 470 TV lines (NTSC) / 480 TV lines (PAL) |
| Power consumption (analog model) | 10 W |
| Power consumption (IP model) | 14 W |
| Operating temperature (indoor) | –10 °C to 50 °C (14 °F to 122 °F) |
| Ingress protection rating | IP66 |
| Video output level | 1.0 Vp‑p, 75 Ω |
The system supports up to 64 preset positions.
The camera requires a 21‑30 VAC, 50/60 Hz power source.
