FrSky ARCHER GR8 is a receiver of FrSky ACCESS protocol, with 4 high-precision PWM channel outputs. It supports full-range signal strength, with dual detachable antennas to assure optimal antenna reception and maximum range. The built-in S.Port connector allows connection with other FrSky ACCESS capable receivers to achieve redundancy receiver.
The document provides an instruction manual for the FrSky ARCHER GR8 Receiver. It details the LED status indicators (Green/Red) corresponding to various states such as successful binding, normal working conditions, and failsafe triggers. The text also lists key specifications including dimensions, weight, channel configuration, and operating voltage.
| Dimension | 30*17*6.2mm (L*W*H) |
|---|---|
| Weight | 3.8g |
| Configurable SBUS Channels | 16/24 |
| PWM Channels | 4 High-precision |
| Operating Voltage Range | 3.5 -10V |
| Control Range | Full range* with telemetry |
Go to the receiver [Options] in the transmitter menu and select 7ms PWM or not; the factory default is FS mode.
You should not perform the binding operation in the near range while the firmware upgrading is in progress.
