FrSky G-RX8 8/24CH telemetry receiver has 24 channels, supports high precision differential altimeter and voltage sensor, can be used for a variety of remote control aircraft.
The FrSky G-RX8 is a high-speed telemetry receiver supporting up to 24 channels with an operating voltage range of 3.5V to 10V. It features a Smart Port (S. Port) for digital transmission and supports both HS (High Speed) and FS (Normal Speed) modes for servo frame rates.
| Dimension | 55.26*17*8mm (L × W × H) |
|---|---|
| Weight | 5.8g |
| Number of Channels | 24CH |
| Operating Voltage Range | 3.5V~10V |
| Operating Current | 100mA@5V |
Bring the receiver into normal operational mode, hold the F/S button for more than 3 seconds until the BLUE LED flashes 3 times.
Connect CH1 and CH2 signal pins with the included jumper to enter SBUS mode; leave them unconnected for PWM mode.
