The RB-30/RB-40 is a new red redundant power controller from FrSky, with triple redundancy functions, can provide up to 24 high-voltage servos with overload protection, and has a built-in gyroscope and a variety of sensors. Supports NFC switch and automatic data logging function.
The FrSky RB-30/RB-40 is an upgraded redundancy hub designed to meet growing user needs by offering a triple-redundancy system. It supports connecting up to 24 high-voltage servos with overload protection on each channel. The device features dual power inputs and utilizes standard XT30/XT60 plugs for safe and efficient power distribution.
| Dimensions (RB-30) | 114.4*73.4*18.7mm |
|---|---|
| Dimensions (RB-40) | 163.2*100*23.5mm |
| Weight (RB-30) | 100g |
| Weight (RB-40) | 260g |
| Power Connector (RB-30) | XT30 |
| Power Connector (RB-40) | XT60 |
| Number of Servos | up to 24 |
| Operating Temperature | -20℃~75℃ |
The allowed continuous current output on CH1~CH24, S.PORT, RX 1IN, RX 2IN,RX3 IN is 5A.
Yes, it supports connecting up to 24 high-voltage servos with overload protection added to each output channel.
Yes, it is an extensive sensor module with a built-in gyroscope that supports model stabilizing functions.
