Please read these instructions completely before attempting to connect, operate or adjust this product
The Panasonic AW-LH 30H is a multi-function controller designed to control one or more pan-tilt head systems, each consisting of a pan-tilt head and a convertible camera. The unit processes video signals and provides cable compensation, connecting to the pan-tilt heads via a supplied 10-meter cable. Up to three control panels can be connected to the main unit, and up to five pan-tilt head systems can be supported in total.
| Maximum connected control panels | Up to three |
|---|---|
| Maximum connected pan-tilt head systems | Up to five |
| Connection cable length | 10 m |
| Extended connection distance (AW-PH350) | 1,000 meters |
| Extended connection distance (other models) | 800 meters |
| Supported pan-tilt heads | AW-PH300, AW-PH300A, AW-PH350, AW-PH500, AW-PH600 |
Up to three control panels can be connected to the main unit.
The unit can support up to five pan-tilt head systems.
The supported models are AW-PH300, AW-PH300A, AW-PH350, AW-PH500, and AW-PH600.
