The Panasonic AW-HB505 Multiport Hub is designed to be combined with the Multi-Hybrid Control Panel (AW-RP505) to control up to five Pan/Tilt Heads (AW-PH300) and Color Video Cameras (AW-E560). It allows for various control operations, sending and receiving camera video signals, and genlock signals. The hub connects to the control panel via coaxial and 10BASE T cables, with a maximum cable length of 10 meters between the panel and the hub, and 500 meters between the hub and the connected devices.
| Operating temperature | -10°C to +45°C |
|---|---|
| Dimensions | 420 (W) x 88 (H) x 250 (D) mm |
| Weight | 4 kg (8.8 Ibs.) |
| Max cable length (Panel to Hub) | 10 meters |
| Max cable length (Hub to devices) | 500 meters |
It can control up to five Pan/Tilt Heads (AW-PH300) and Color Video Cameras (AW-E560).
The manual specifies using the AC Adaptor, Model AW-PS505.
The maximum cable length between the Multiport Hub and the cameras and pan/tilt heads is 500 meters.
