This document is an instruction manual for the Convertible Camera AW-E860N, including information on how to operate, connect, and adjust the product, as well as safety precautions. The camera complies with FCC regulations and is suitable for commercial use.
This document provides operating instructions for the Panasonic AW-E860N, a digital signal processing color video camera featuring three 2/3" wide CCDs. The manual details system configurations involving peripheral devices like RCU, RCB, and various lenses, as well as optional card installations.
| Resolution | 850 lines (HIGH BAND DTL: ON) |
|---|---|
| S/N ratio | 65 dB (DNR ON) |
| Minimum illumination | 0.4 Ix (F1.7, Night eye H mode) |
It must be replaced about every 30,000 hours.
The internal cooling fan is an expendable part that must be replaced about every 30000 hours.
The camera has a minimum illumination of 0.4 lx when operating in F1.7 Night eye H mode.
