SCS1 is an user-friendly vision sensor equipped with advanced inspection capability that assures very precise quality controls on industrial manufacturing and automatic processes.
The Datasensor SCS1 is an user-friendly vision sensor designed for precise quality controls on industrial manufacturing and automatic materials handling lines. It utilizes vision techniques to acquire reference images of target objects and compare them with the target images to ensure quality.
| Network Communication | Ethernet 10/100 Mbps |
|---|---|
| Power Supply | 24 Vdc |
| Lens Mount | 16 mm C-mount |
| Connectors | M8, M12 |
The SCS1 sensor can be configured using the integrated user interface based on display and push-buttons, or using the SCS1 graphic interface with a PC connection.
It is used for precise quality controls on industrial manufacturing and automatic materials handling lines by comparing target objects to a reference image.
Typical applications include checking label presence on bottles, performing contour control, and conducting component control on PCBs.
The sensor requires a 24 Vdc power supply connected to the brown wire on the M12 connector.
