The 74VHC132 is a quad 2-input NAND Schmitt trigger with features such as high speed, low power dissipation, and low noise. It can be used to interface 5V to 3V systems and two supply systems.
The 74VHC132 is an advanced high-speed CMOS 2-input NAND Schmitt Trigger Gate fabricated with silicon gate CMOS technology. It achieves high-speed operation similar to Bipolar Schottky TTL while maintaining low power dissipation. The device features inputs with hysteresis between positive-going and negative-going thresholds, providing greater noise margin than conventional gates. An input protection circuit ensures that 0V to 7V can be applied to input pins without regard to supply voltage, allowing use in 5V to 3V systems and two-supply systems.
| Supply Voltage Range | 2.0V to +5.5V |
|---|---|
| Operating Temperature Range | -40°C to +85°C |
It is a Quad 2-Input NAND Schmitt Trigger Gate with high-speed operation and low power dissipation.
Yes, the pin configuration and function are the same as the 74HC132.
