NC7WZ38 TinyLogic UHS Dual 2-Input NAND Gate (Open Drain Output) is a high-performance NAND gate circuit with advanced CMOS technology, ultra-high speed, high output drive, low static power consumption and other features.
The NC7WZ38 is a dual 2-input NAND gate with an open drain output stage, part of Fairchild's Ultra High Speed Series of TinyLogic devices. Fabricated with advanced CMOS technology, it offers ultra-high speed operation with high output drive and low static power dissipation across a broad operating voltage range.
| Supply Voltage Range | 1.65V to 5.5V |
|---|---|
| Propagation Delay (Typ) | 2.2 ns |
| Output Sink Drive | 24 mA |
| Package Type | 8-Lead US8 or 8-Lead MicroPak |
The device features an open drain output stage.
Yes, inputs tolerate voltages up to 7V independent of Vcc.
The device is specified to operate over a range starting at 1.65V.
