The NC7SZ38 is a single 2-Input NAND gate with open drain output stage from Fairchild’s Ultra-High Speed Series of TinyLogic®. The device is fabricated with advanced CMOS technology to achieve ultra-high speed with high output drive while maintaining low static power dissipation over a very broad VCC operating range.
The document describes the NC7SZ38, a single 2-Input NAND gate from Fairchild's Ultra-High Speed Series of TinyLogic. The device is fabricated with advanced CMOS technology to achieve ultra-high speed with high output drive while maintaining low static power dissipation over a very broad Vcc operating range.
| Propagation Delay (Typical) | 2.4ns into 50pF at 5V Vcc |
|---|---|
| Output Sink Drive | 24mA at 3V Vcc |
| Operating Voltage Range | 1.65V to 5.5V |
| Input Tolerance | Up to 6V independent of Vcc |
It is a single 2-Input NAND gate with an open drain output stage.
The device is available in SOT23, SC70, and MicroPak packages.
