This document provides installation and operation instructions for the Lowrance M52 S/GPS Fish-finding Sonar & GPS Plotter, including features and specifications of the product.
This manual provides comprehensive installation and operation instructions for the Lowrance M52 S/GPS, a combination fish-finding sonar and GPS plotter. It covers preparations, transducer installation (shoot-thru-hull and transom mount), and mounting the sonar unit. The guide also details basic sonar operation, including keyboard usage, memory management, and various sonar options like ASP and Fish I.D. Additionally, it explains GPS operations, including waypoint creation, route navigation, and system setup options.
| Display Resolution | 160 pixel x 240 pixel |
|---|---|
| Input Power | 10 to 17 volts DC |
| Sonar Frequency | 200 kHz |
| Transmitter Power | 800 watts peak-to-peak |
| Sounding Depth Capability | 600 feet |
| GPS Position Points | 1,000 waypoints |
| Routes Capacity | 100 routes |
The sonar frequency is 200 kHz.
The unit can store 1,000 waypoints.
The capability is up to 600 feet, though actual depth depends on conditions.
