The CBTS3306 is a dual bus switch with Schottky diode clamping. It features a 5Ω switch connection between two ports, TTL-compatible input levels, and package options including plastic small outline (SO) and thin shrink small outline (TSSOP). The device also has latch-up protection exceeding 100mA per JESD78 and ESD protection exceeding 2000V HBM per JESD22-A114. The CBTS3306 is characterized for operation from -40 to +85 °C.
The Philips CBTS3306 is a dual FET bus switch designed to connect two ports with independent line switches. It features Schottky diodes on the I/Os specifically to clamp undershoot voltages. The device includes latch-up protection exceeding 100 mA and ESD protection exceeding 2000 V HBM.
| Operating Temperature Range | -40 to +85 °C |
|---|---|
| Latch-up Protection | > 100 mA |
| ESD Protection (HBM) | > 2000 V |
The device is available in plastic small outline (SO) and thin shrink small outline (TSSOP) packages.
The absolute maximum DC supply voltage rating is +7.0 V.
