74F1244 is an Octal buffer (3-State) produced by Philips Semiconductors. It is ideal for driving bus lines or buffer memory address registers. The outputs are capable of sinking 64mA and sourcing up to 15mA, producing very good capacitive drive characteristics. The device features two Output Enables, OEa and OEb, each controlling four of the 3-State outputs. The 74F1244 is pin and functionally compatible with the 74F244. The lower power and light bus loading features make it an ideal part to interface directly with MOS microprocessors.
The Philips 74F1244 is an octal buffer designed for driving bus lines or buffering memory address registers. It features high impedance NPN base inputs to reduce loading and low power consumption, making it ideal for interfacing with MOS microprocessors. The device provides 3-State outputs that can sink 64mA and source 15mA, offering superior capacitive drive characteristics compared to the 74F244.
| Supply Voltage (VCC) | 4.5V to 5.5V |
|---|---|
| Operating Temperature Range | 0°C to +70°C |
| Output Sink Current | 64mA |
| Output Source Current | 15mA |
| Input Current (High/Low) | 20µA |
The 74F1244 is a pin and functionally equivalent of the 74F244.
It is an octal buffer with eight outputs.
The device features two Output Enables, OEa and OEb, each controlling four of the 3-State outputs.
