The CBTD16213 is a 24-bit level shifting bus exchange switch with 12-bit output enables. It features 5 Ohm switch connection between two ports, TTL compatible control input levels, designed to be used in level shifting applications. The device has plastic shrink small outline (SSOP) and thin shrink small outline (TSSOP) package options, and is tested to JESDEC Standard JESD78 which exceeds 100 mA latch-up. It also exceeds JESD22-114A's 1500V HBM and JESD22-C101's 1000V CDM ESD protection.
The Philips CBTD16213 is a high-speed TTL-compatible integrated circuit designed for 24-bit bus switching or exchanging. It features a built-in diode to Vcc, enabling level shifting between 5 V inputs and 3.3 V outputs. The device operates as either a 24-bit bus switch or a 12-bit bus exchanger, routing data between four signal ports via data-select terminals.
| DC supply voltage (Vcc) | 4.5 to 5.5 V |
|---|---|
| Package options | SSOP and TSSOP |
Yes, it includes an integrated diode to Vcc that allows level shifting between 5 V inputs and 3.3 V outputs.
The device allows connections between 5 V inputs and 3.3 V outputs.
The plastic shrink small outline (SSOP) package has 56 leads.
