The LMX1600/01/02 is part of a family of monolithic integrated dual frequency synthesizers designed to be used in a local oscillator subsystem for a radio transceiver.
The LMX1600/01/02 is a family of monolithic integrated dual frequency synthesizers fabricated using National's 0.5u ABiC V silicon BICMOS process. These devices are designed to be used in a local oscillator subsystem for radio transceivers and contain two dual modulus prescalers, four programmable counters, two phase detectors, and two selectable gain charge pumps.
| Supply Voltage Range | 2.7V to 3.6V |
|---|---|
| Typical Current Consumption (LMX1601) | 4.0 mA at 3V |
| Typical Current Consumption (LMX1600/02) | 5.0 mA at 3V |
| Operating Temperature Range | -40 to +85 C |
| Main Operating Frequency (2 GHz Option) | 200 to 2000 MHz |
| Aux Operating Frequency | 40 to 500 MHz |
| Package Type | 16 pin TSSOP |
The typical current consumption for the LMX1601 is 4.0 mA at 3V.
The Vee supply voltage can range from 2.7V to 3.6V.
The recommended operating temperature range is -40 C to +85 C.
