The LMC6032 is a CMOS dual operational amplifier manufactured by National Semiconductor Corporation. The chip is built with the company's advanced Double-Poly Silicon-Gate CMOS process and supports single and dual power supplies. It features an input common-mode range that reaches ground, low input bias current and high voltage gain. The device is suitable for applications such as high-impedance buffer or preamplifier, current-to-voltage converter, long-term integrator, sample-and-hold circuit and medical instrumentation.
The LMC6032 is a CMOS dual operational amplifier capable of operating from single or dual power supplies. Key features include an input common-mode range that reaches ground, ultra-low input bias current of 40 fA, and high voltage gain suitable for loads of 2 kΩ and 600Ω. The device is built using National Semiconductor's advanced Double-Poly Silicon-Gate CMOS process.
| Input Bias Current | 40 fA |
|---|---|
| Voltage Gain (2 kΩ load) | 126 dB |
| Total Harmonic Distortion | 0.01% at 10 kHz |
| Supply Voltage Range | +5V to +15V |
| Gain-Bandwidth Product | 14 MHz |
| Phase Margin | 50° |
The input bias current is 40 fA.
The device operates from a supply range of +5V to +15V.
It can operate from either a single supply or dual supplies.
