LMC6482 is a dual rail-to-rail input and output operational amplifier from ti. It features low input current, high voltage gain and high common-mode rejection ratio (cmrr). It is ideal for systems that require a large input signal range, such as data acquisition systems.
The LMC6482 is a CMOS dual rail-to-rail input and output operational amplifier designed for systems requiring a large input signal range, such as data acquisition and medical instrumentation. It features a common-mode voltage range that extends to both supply rails and offers excellent accuracy with a high Common Mode Rejection Ratio (CMRR). The device is also available in a smaller MSOP package compared to the standard SO-8 device.
| Input Offset Voltage (Typical) | 0.11 mV |
|---|---|
| Voltage Gain (RL=500 kΩ) | 130 dB |
| Output Swing (RL=2kΩ) | within 20 mV of supply rail |
| Supply Voltage Range | 3.0V to 15.5V |
| Gain-Bandwidth Product (V+=15V) | 1.5 MHz |
It is ideal for data acquisition systems, transducer amplifiers, hand-held analytic instruments, and medical instrumentation.
Yes, its guaranteed low voltage characteristics and low power dissipation make it especially well-suited for battery-operated systems.
The maximum supply voltage is 16V, as indicated in the absolute maximum ratings.
