The PCA82C250 is a high-performance CAN controller interface for automotive environments that has the following features: full compatibility with ISO 11898 standard, high speed (up to 1 Mbaud), bus lines protected against transients in an automotive environment, slope control to reduce Radio Frequency Interference (RFI), wide common-mode range differential receiver for high immunity against ElectroMagnetic Interference (EMI), thermal protection, short-circuit proof to battery and ground, low-current standby mode, an unpowered node does not disturb the bus lines, at least 110 nodes can be connected
The Philips PCA82C250 is an integrated circuit serving as the interface between a CAN protocol controller and the physical bus. Designed for high-speed applications up to 1 Mbaud in automotive environments, it provides differential transmit and receive capabilities. The device is fully compatible with the ISO 17898 standard and includes features such as slope control to reduce Radio Frequency Interference (RFI) and protection against electrical transients.
| Maximum transmission speed | 1 Mbaud |
|---|---|
| Supply voltage | 4.5 to 5.5 V |
| Maximum ambient temperature | +125 °C |
| Package type | DIP8 |
The device supports high-speed applications up to 1 Mbaud.
Yes, the device is fully compatible with the ISO 17898 standard.
The supply voltage range is 4.5 V to 5.5 V.
