Agilent Vertical Pipetting Station is the fastest precision pipettor on the market, delivering industry-leading speed and unparalleled performance for sample handling and liquid-transfer applications.
The Agilent G5401A Vertical Pipetting Station is a precision liquid handling device designed for high-speed sample transfer and plate replication. It features interchangeable heads for 8, 16, 96, and 384-channel operations and is powered by Agilent VWorks Automation Control software.
The device supports various microplate formats (96, 384, and 1536-well) and utilizes certified disposable or fixed pipette tips. Key specifications include a cycle time of 10 seconds for microplate transfers, precise X/Y/Z positioning, and specific operating requirements for electrical power, air pressure, and vacuum.
| Cycle Time | 10 seconds |
|---|---|
| Positioning Precision | 0.025mm |
| Shelf Positions | 8 |
| Operating Temperature | 4-40 °C |
| Air Requirement | 28 Lpm at 6.2-6.9 bar |
| Weight | 37.2 kg [82 lbs] |
The station is powered by Agilent VWorks Automation Control software.
The station supports 96-, 384-, and 1536-well microplates.
