This document provides product information for the Dallas Semiconductor DS907x series of SIP Stik Connectors. These components provide a snap-in connection between SIP Stiks and motherboards, featuring low insertion force and redundant contacts.
The document lists specific part numbers such as the DS9072-40V and DS9072H-40R, detailing their contact counts, profiles (vertical, high profile, low profile), and angles. It also describes 40-position DIP-to-SIP and SIP-to-DIP adaptors designed for the development of DS2250 Micro Stik products.
| Pitch | .050 inch |
|---|---|
| Contact Count (DS9072) | 40 or 72 contacts |
| Connector Type | SIP Stik Connectors |
The pitch for the listed Molex part numbers is .050 inch.
They are 40-position DIP-to-SIP and SIP-to-DIP adaptors for the development of DS2250 Micro Stik products.
