The MIDIMAN Fineline Manual introduces the product's functions and features, including the front panel, rear panel, left and right inputs, headphone output, send inputs, send output, power indicator, etc.
The MIDIMAN Fineline is a compact audio expansion unit designed to mix multiple signals in a quiet, transparent manner. It functions as either a 10-channel stereo or 20-channel mono line mixer, allowing users to control levels, panning, and effects primarily at the source.
| Channels (Stereo) | 10 channel |
|---|---|
| Channels (Mono) | 20 channel |
| Power Supply | 9 to 12 volts AC |
| Left/Right Level Gain (Max) | 12 dB |
| Send Gain (Max) | 6 dB |
The device runs on 9 to 12 volts AC.
In Stereo mode, Left and Right inputs mix separately; in Mono mode, all 20 inputs are combined and fed to both outputs.
The signal appears at the Send mix Output with an additional gain of 6 dB.
