The SAM™ 2 4 BIT / PDIF / ADAT MIXER & FORMAT CONVERTER 1 MANUAL G U A R A N T E E D F O R L I F E introduces the features and characteristics of the product.
The MIDIMAN SAM is a digital audio interface device that converts between ADAT Optical and S/PDIF signals. It features six selectable modes, including a digital mixer with independent gain and pan controls for eight ADAT inputs, and transparent format conversion modes for routing specific track pairs. The device supports sample rates from 39 kHz to 51 kHz and utilizes internal high-performance DSP for 56-bit processing in mix mode.
| Sample Rate Support | 39 kHz to 51 kHz |
|---|---|
| Mix Mode Resolution | 56-bit internal processing |
| Power Supply | 9 Volt DC, 500 milliamp |
| Dimensions | 7" x 4.5" x 1" |
The SAM has six different selectable modes to convert between ADAT Optical Digital Interface and S/PDIF interface signals.
The red LED lights on the output level displays indicate that the signal level exceeds -1 dB.
