This document describes the features and characteristics of CAT.8100V aluminum electrolytic capacitors RS series. This series has more compact and low-profile case sizes compared to the VS series. It complies with the RoHS directive. It has low leakage current, stable performance at low temperatures, and endurance.
This datasheet describes the Panasonic CAT.8100 RS series of aluminum electrolytic capacitors. The series is designed to be more compact and low-profile than the VS series and is adapted to the RoHS directive (2002/95/EC). These radial lead type capacitors are suitable for power filtering and energy storage applications in industrial electronic devices.
| Temperature Range | -40 ~ +85˚C |
|---|---|
| Rated Voltage Range | 6.3 ~ 400V |
| Rated Capacitance Range | 0.1 ~ 10000µF |
| Capacitance Tolerance | ±20% |
| Leakage Current (1 min) | 0.03CV or 4 (µA), whichever is greater |
| Leakage Current (2 min) | 0.01CV or 3 (µA), whichever is greater |
| Endurance | 2000 hours at 85˚C |
| Shelf Life | 1000 hours at 85˚C |
Yes, the series is adapted to the RoHS directive (2002/95/EC).
The capacitance tolerance is ±20%.
