The THS1215 is a low power, 12-bit, 15 MSPS analog-to-digital converter (ADC) that operates with a 3.3-V supply. It can be configured as a single-ended input, a single-ended input with offset, or a differential input. The THS1215 also provides a wide selection of voltage references to meet user design requirements. Additionally, the THS1215 provides an output to monitor any out-of-range condition in the THS1215's input range. The THS1215's speed, resolution, and single-supply operation make it well suited for applications in video, multimedia, high-speed acquisition, and communications.
The THS1215 is a CMOS, low-power analog-to-digital converter (ADC) that operates with a single 3.3-V supply. It provides circuit developers complete flexibility by supporting configurable input functions including single-ended, single-ended with offset, and differential modes. The device features an internal voltage reference that can be bypassed for external references to suit specific accuracy and temperature drift requirements.
| Resolution | 12 Bits |
|---|---|
| Operating Junction Temperature (Commercial) | -40°C to 70°C |
| Operating Junction Temperature (Industrial) | -40°C to 85°C |
| Analog Input Bandwidth | 180 MHz |
The device is available in a 28-TSSOP (PW) and a 28-SOIC (DW) package.
Yes, the internal reference can be bypassed to use an external reference for specific accuracy and temperature drift requirements.
